SS Wire Drawing Machine

Home Single Wire Drawing Machine SS Wire Drawing Machine

SS Wire Drawing Machine

Machine's body is is welded by steel plates, after annealing treatment, removal the internal stress and after the precision milling machine, one hole completion,has the advantages of not deformation and high precision.

Main feature:

1) Max.Dies Qty: 23

2) Outlet wire size: 0.1-0.2mm

3) Max speed: 800m/min

Single Wire Drawing Machine, Steel Wire Drawing Machine2022-10-11m90

Description

1. Application:

SS Wire Drawing Machine is mainly used for drawing stainless steel wire,low carbon wire,galvanized iron wire,etc.

2.Parameters:

Max Dies No 23
Max inlet wire dia. 0.7mm
Finish wire dia. 0.1-0.2mm
Max line speed 800m/min
Traversing type 100kw Synchronous motor + flat belt
Brake type Electromagnetic brake
Take-up motor 800m/min
Main motor 2.2kw
Take-up bobbin size 200mm
Lubrication type Full immersion
Transmission type Flat belt

3.Advantages:

1.The traversing speed can be adjusted automatically according to the take-up speed, and the traversing is stable

2.Synchronous belt transmit every wire drawing shaft,take-up shaft is driven by a separate motor independently,and also Independent matching the inverter.

3.Long service life.

4.Delivery time: 30-45 working days

5.After-sell service:

Engineer will be dispatched at needed.

The buyer provides engineer’s round trip flight tickets, board and lodging, the security as well as each person of daily wage.

6.Guarantee: 12 months since shipping date(exclude easily wearing part)

Click here to find out more about different types of Steel Wire Drawing Machine
